ASCO Type Pulse Jet Valve

Name: ASCO Type Pulse Jet Valve
Brand: BRANDO
Price: 1 USD

Brand Name : BRANDO

Model Number : 353

Certification : CE

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union, L/C, MoneyGram

Supply Ability : 165000 pieces per month

Delivery Time : 4-7 days

Packaging Details : Inner Box,Carton,Pallet

Port Size : 3/4'', 1'', 1.5'', 2'', 2.5'', 3''

Valve Operation : Diaphragm Pilot Operated

Coil Voltage : 24VDC, 110VAC, 220VAC

Workinｇ Pressure Range : 0.35 to 0.85 MPa

Threaded Valve : SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051

Remote Pilot Valve : G353A041, G353A042, G353A045

Immersion Valve : SCXE353.060

Diaphragm Material : TPE, NBR, FKM

Contact Now

ASCO Type Pulse Jet Valve

ASCO Type 353 Series Pulse Jet Valve:

1. Threaded Pulse Jet Valve: SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051.

2. Remote Pilot Pulse Jet Valve: G353A041, G353A042, G353A045.

3. Immersion Pulse Jet Valve: SCXE353.060.

Pulse jet valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device.Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.

Data of Threaded Pulse Jet Valves:

Model	SCG353A043	SCG353A044	SCG353A047	SCG353A050	SCG353A051
Port Size	3/4''	1''	1 1/2''	2''	2 1/2''
Voltages	24VDC, 24VAC, 110VAC, 220VAC
Diaphragm Number	1		2
Working Pressure Range	0.35 to 0.85 MPa
Diaphragm Material	TPE, NBR, FKM
Fluids	Air
Valve Structure	Right Angle, Threaded Port

Data of Remote Pilot Pulse Jet Valves

Port Size	Remote Pilot Connection	Office Size	Operating Pressure Differential (Bar)		Model Number	Diaphragm Material
G	φB	(mm)	Min.	Max.	Aluminium	NBR
G	φB	(mm)	Min.	Max.	Aluminium
3/4''	1/8''	24	0.35	8.5	G353A041
1''	1/8''	27	0.35	8.5	G353A042
1 1/2''	1/8''	52	0.35	8.5	G353A045

Video of ASCO Type Pulse Jet Valves:

More ASCO Type Pulse Valve For You to Choose:


Threaded Type	Remote Pilot Type	Straight Through Type	Submerged Type

Diaphragm	Solenoid Coil	Solenoid Armature	Pulse Controller

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
